E Series™ Engines

E Series™ Engines

Reliable performance. Exceptional value.

Ideal for smaller acreage lawns, our E Series riding mower engines are powerful, yet lightweight. Their performance-enhancing features deliver more than you’d expect, at a great value.

  • Advanced Debris Management – Helps our engines run cleaner and longer by deflecting and ejecting grass and debris, providing a longer life.
  • Anti-Vibration System® (AVS®) – Counterbalanced internal components give you a smoother ride and save wear and tear on your engine, your equipment – and you.
  • Splash Lubrication System – As the engine is running, a spinning gear with paddles slings oil on critical components for vital lubrication and reduced wear.
  • Made in the USA of US and global parts.

10.5 - 17.5

Gross Horsepower (ft-lbs)

344 - 500cc

Displacement

Gas

Engine Fuel

48

Oil Capacity (oz)

Features

Made in the USA

Made in the USA of US and global parts.

Anti-Vibration System - AVS®

Provides a smoother ride and more comfort.

Advanced Debris Management System

Keeps the engine clean by deflecting and ejecting grass and debris for a longer engine life.

Specs

Only 2 products can be compared at once. Please remove one of your selections to compare this product.

Only 3 products can be compared at once. Please remove one of your selections to compare this product.

At least one product must be displayed. Please select another option to remove this product

Model Number
21R7
Torque (ft-lbs, gross)*
10.5
Engine Displacement (cc)
344
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
17.8
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
66
Bore (in)
3.44
Stroke (in)
2.26
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
0.7 (optional)
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric Start, Recoil Optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
21R8
Torque (ft-lbs, gross)*
11.5
Engine Displacement (cc)
344
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
17.8
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
66
Bore (in)
3.44
Stroke (in)
2.26
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
0.7 (optional)
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric Start, Recoil Optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
31R5
Torque (ft-lbs, gross)*
13.5
Engine Displacement (cc)
500
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
18.9
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
77
Bore (in)
3.56
Stroke (in)
3.06
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
N/A
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric Start, Recoil Optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
31R6
Torque (ft-lbs, gross)*
14.5
Engine Displacement (cc)
500
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
18.9
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
77
Bore (in)
3.56
Stroke (in)
3.06
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
N/A
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric Start, Recoil Optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
31R7
Torque (ft-lbs, gross)*
15.5
Engine Displacement (cc)
500
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
18.9
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
77
Bore (in)
3.56
Stroke (in)
3.06
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
N/A
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric Start, Recoil Optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
31R8
Torque (ft-lbs, gross)*
16.5
Engine Displacement (cc)
500
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
18.9
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
77
Bore (in)
3.56
Stroke (in)
3.06
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
N/A
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric Start, Recoil Optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
31R9
Torque (ft-lbs, gross)*
17.5
Engine Displacement (cc)
500
Number of Cylinders
Single
Engine Configuration
Vertical Shaft
OHV Engine
Yes
Length (in)
18.9
Width (in)
15.5
Height (in)
12.9
Weight (lbs)
77
Bore (in)
3.56
Stroke (in)
3.06
Engine Fuel
Gasoline
Fuel Tank Capacity (gal)
N/A
Lubrication System
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
Oil Filter
N/A
Starter
Electric start, recoil optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Certified Power Rating
Fuel Shutoff Valve
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

Model Number
21R7
21R8
31R5
31R6
31R7
31R8
31R9
Torque (ft-lbs, gross)*
10.5
11.5
13.5
14.5
15.5
16.5
17.5
Engine Displacement (cc)
344
344
500
500
500
500
500
Number of Cylinders
Single
Single
Single
Single
Single
Single
Single
Engine Configuration
Vertical Shaft
Vertical Shaft
Vertical Shaft
Vertical Shaft
Vertical Shaft
Vertical Shaft
Vertical Shaft
OHV Engine
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Length (in)
17.8
17.8
18.9
18.9
18.9
18.9
18.9
Width (in)
15.5
15.5
15.5
15.5
15.5
15.5
15.5
Height (in)
12.9
12.9
12.9
12.9
12.9
12.9
12.9
Weight (lbs)
66
66
77
77
77
77
77
Bore (in)
3.44
3.44
3.56
3.56
3.56
3.56
3.56
Stroke (in)
2.26
2.26
3.06
3.06
3.06
3.06
3.06
Engine Fuel
Gasoline
Gasoline
Gasoline
Gasoline
Gasoline
Gasoline
Gasoline
Fuel Tank Capacity (gal)
0.7 (optional)
0.7 (optional)
N/A
N/A
N/A
N/A
N/A
Lubrication System
Dura-Lube Splash Lubrication
Dura-Lube Splash Lubrication
Dura-Lube Splash Lubrication
Dura-Lube Splash Lubrication
Dura-Lube Splash Lubrication
Dura-Lube Splash Lubrication
Dura-Lube Splash Lubrication
Oil Capacity (oz)
48
48
48
48
48
48
48
Oil Filter
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Starter
Electric Start, Recoil Optional
Electric Start, Recoil Optional
Electric Start, Recoil Optional
Electric Start, Recoil Optional
Electric Start, Recoil Optional
Electric Start, Recoil Optional
Electric start, recoil optional
Air Filter
Cartridge Air Cleaner with Advanced Debris Management
Cartridge Air Cleaner with Advanced Debris Management
Cartridge Air Cleaner with Advanced Debris Management
Cartridge Air Cleaner with Advanced Debris Management
Cartridge Air Cleaner with Advanced Debris Management
Cartridge Air Cleaner with Advanced Debris Management
Cartridge Air Cleaner with Advanced Debris Management
Muffler
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Fuel Shutoff Valve
Optional
Optional
Optional
Optional
Optional
Optional
Optional

*All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
**All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.
