CXi Series Engines (Large)
Commercial performance, reliable power.
These V-Twin engines are specially designed for zero turn mowers and other high-debris applications to endure extended use in extreme conditions. Cyclonic air filtering keeps dirt out and extends engine life. The V-Twin design delivers more power, is naturally balanced for less vibration, runs cooler and cleaner.
- Optional Oil Xtend with 250 hour maintenance.
- Strengthened cylinder, sump and rod for durability.
- Premium oil and fuel filters protect the engine.
- Available Electronic Fuel Injection (EFI) and Electronic Throttle Control (ETC) on select engines.
- 3-Year commercial and consumer warranty.
- 5-Step Cyclonic Debris Management.
- Made in the USA of US and global parts.
To learn more, download our product literature.
Gross Horsepower (HP)
20.0 - 25.0
Displacement (cc)
656 - 810
Oil Capacity (L)
1.9
Fuel Type
Gasoline
Features
Made in the USA
Made in the USA of US and global parts.
Patented 5-Step Integrated Cyclonic Debris Management System
Extended durability under heavy debris conditions.
V-Twin Engine
For more power, comfort and durability.
Specifications
Selected Models:
| 20.0 Gross HP** | 23.0 Gross HP** | 25.0 Gross HP** | |
| Engine Series | CXi Series | CXi Series | CXi Series |
| Gross Power HP (kW) @3'600 rpm | 20.0 | 23.0 | 25.0 |
| Engine Displacement (cc) | 656 | 724 | 724 |
| Cylinders | V-Twin | V-Twin | V-Twin |
| Engine Configuration | Vertical Shaft | Vertical Shaft | Vertical Shaft |
| Start Type | Electronic Start | Electronic Start | Electronic Start |
| Engine Fuel | Gasoline | Gasoline | Gasoline |
| Length (in) | 485 | 485 | 485 |
| Width (in) | 462 | 462 | 462 |
| Height (in) | 399 | 399 | 399 |
| Weight (kg) | 38.1 | 38.1 | 38.1 |
| Bore (mm) | 75.4 | 79.2 | 79.2 |
| Stroke (mm) | 73.40 | 73.40 | 73.40 |
| Oil Capcity (L) | 1.90 | 1.90 | 1.90 |
| Lubrication System | Full Pressure Lubrication | Full Pressure Lubrication | Full Pressure Lubrication |
| Oil FIlter | Premium | Premium | Premium |
| Air Filter | Integrated Cyclonic Air Cleaner - Patented 5 Step | Integrated Cyclonic Air Cleaner - Patented 5 Step | Integrated Cyclonic Air Cleaner - Patented 5 Step |
| Muffler | N/A | N/A | N/A |
| Certified Power Rating | Download Power Curve | Download Power Curve | Download Power Curve |
| Warranty | 3 Years | 3 Years | 3 Years |
*All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.
