    E Series™ Engines

    E Series Engines
    E Series Engines
    E Series Engines
    E Series Engines
    E Series Engines

    E Series™ Engines

    Easy to use. Exceptional value.

    • Prime n' Pull Start
    • Dura-Lube Splash Lubrication

    125 - 140cc

    Displacement (cc)

    Prime n' Pull™

    Starter

    Gas

    Engine Fuel

    4.50 - 5.50

    Gross Torque (ft-lbs)
    Feature

    Features

    No Prime, No Choke

    1-Step Start, just pull for power.

    Lo-Tone™ Muffler

    Delivers low noise and good tonal quality.

    Tool-less Air Cleaner Cover

    Easy access for filter changes.

    Specifications

    Only 2 products can be compared at once. Please remove one of your selections to compare this product.

    Only 3 products can be compared at once. Please remove one of your selections to compare this product.

    At least one product must be displayed. Please select another option to remove this product

    Model Number
    08P5
    Torque (ft-lbs, gross)*
    4.5
    Displacement (cc)
    125
    Cylinders
    Single
    Engine Configuration
    Vertical Shaft
    OHV Engine
    true
    Length (in)
    13.8
    Width (in)
    12.2
    Height (in)
    9.6
    Weight (kg)
    17
    Stroke (mm)
    1.75
    Engine Fuel
    Gasoline
    Fuel Tank Capacity (gal)
    0.2
    Oil Capacity (L)
    15
    Lubrication System
    Dura-Lube Splash Lubrication
    Oil Filter
    N/A
    Starter
    Prime n' Pull™
    Air Filter
    Oiled Foam
    Muffler
    Lo-Tone™
    Certified Power Rating
    Download Power Curve
    Application Type
    Push Mower
    Engine Brand
    Briggs & Stratton
    Power Source
    Gas
    Cylinder Bore Size
    2.36

    *All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
    **All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.

    Model Number
    09P6
    Torque (ft-lbs, gross)*
    5
    Displacement (cc)
    140
    Cylinders
    Single
    Engine Configuration
    Vertical Shaft
    OHV Engine
    true
    Length (in)
    13.8
    Width (in)
    12.2
    Height (in)
    9.6
    Weight (kg)
    17
    Stroke (mm)
    1.75
    Engine Fuel
    Gasoline
    Fuel Tank Capacity (gal)
    0.2
    Oil Capacity (L)
    15
    Lubrication System
    Dura-Lube Splash Lubrication
    Oil Filter
    N/A
    Starter
    Prime n' Pull™
    Air Filter
    Oiled Foam or Dual-Sealing Paper
    Muffler
    Lo-Tone™ or Super Lo-Tone™
    Certified Power Rating
    Download Power Curve
    Marketing Fuel Tank Capacity
    0.2
    Application Type
    Push Mower
    Engine Brand
    Briggs & Stratton
    Power Source
    Gas
    Cylinder Bore Size
    2.50

    *All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.

    Model Number
    09P7
    Torque (ft-lbs, gross)*
    5.5
    Displacement (cc)
    140
    Cylinders
    Single
    Engine Configuration
    Vertical Shaft
    OHV Engine
    true
    Length (in)
    13.8
    Width (in)
    12.2
    Height (in)
    9.6
    Weight (kg)
    17
    Stroke (mm)
    1.75
    Engine Fuel
    Gasoline
    Fuel Tank Capacity (gal)
    0.2
    Oil Capacity (L)
    15
    Lubrication System
    Dura-Lube Splash Lubrication
    Oil Filter
    N/A
    Starter
    Prime n' Pull™
    Air Filter
    Oiled Foam or Dual-Sealing Paper
    Muffler
    Lo-Tone™ or Super Lo-Tone™
    Certified Power Rating
    Download Power Curve
    Marketing Fuel Tank Capacity
    0.2
    Application Type
    Push Mower
    Engine Brand
    Briggs & Stratton
    Power Source
    Gas
    Cylinder Bore Size
    2.50

    *All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.

    Model Number
    08P5
    09P6
    09P7
    Torque (ft-lbs, gross)*
    4.5
    5
    5.5
    Displacement (cc)
    125
    140
    140
    Cylinders
    Single
    Single
    Single
    Engine Configuration
    Vertical Shaft
    Vertical Shaft
    Vertical Shaft
    OHV Engine
    true
    true
    true
    Length (in)
    13.8
    13.8
    13.8
    Width (in)
    12.2
    12.2
    12.2
    Height (in)
    9.6
    9.6
    9.6
    Weight (kg)
    17
    17
    17
    Stroke (mm)
    1.75
    1.75
    1.75
    Engine Fuel
    Gasoline
    Gasoline
    Gasoline
    Fuel Tank Capacity (gal)
    0.2
    0.2
    0.2
    Oil Capacity (L)
    15
    15
    15
    Lubrication System
    Dura-Lube Splash Lubrication
    Dura-Lube Splash Lubrication
    Dura-Lube Splash Lubrication
    Oil Filter
    N/A
    N/A
    N/A
    Starter
    Prime n' Pull™
    Prime n' Pull™
    Prime n' Pull™
    Air Filter
    Oiled Foam
    Oiled Foam or Dual-Sealing Paper
    Oiled Foam or Dual-Sealing Paper
    Muffler
    Lo-Tone™
    Lo-Tone™ or Super Lo-Tone™
    Lo-Tone™ or Super Lo-Tone™
    Certified Power Rating
    Download Power Curve
    Download Power Curve
    Download Power Curve
    Application Type
    Push Mower
    Push Mower
    Push Mower
    Engine Brand
    Briggs & Stratton
    Briggs & Stratton
    Briggs & Stratton
    Power Source
    Gas
    Gas
    Gas
    Cylinder Bore Size
    2.36
    2.50
    2.50
    Marketing Fuel Tank Capacity
    0.2
    0.2

    *All power levels are stated gross torque at 2600 rpm per SAE J1940 as rated by Briggs & Stratton.
    **All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.
